12,000 - 18,000 BTU/h ducted unit heat pumps that can operate as an air conditioner and as a heater. This heat pump is 5 times more efficient than using an electric heater. It is at least twice as efficient as a 110 volt window AC unit and effectively three times more efficient when using with an off grid 24 volt system, without requiring an inverter. All parts inside are DC-native. This is "how it's done", if you are serious about the most efficient and reliable heat pump.
True 48 volt DC compressor and fans; this unit does NOT require the use of an inverter. This is the most efficient way for you to control your climate using a 48 volt power supply.
See unit in VR in your building.
Performance - 9,000 BTU/h unit |
||
Capacity |
Cooling |
9,000 BTU/h |
2,500 Watts |
||
Heating |
10,000 BTU/h |
|
2800 Watts |
||
Air Flow |
230 CFM |
|
EER |
W/W |
4.88 |
BTU/h/W |
15.79 |
|
Refrigerant |
R-134A |
|
Compressor |
Panasonic 48VDC |
|
Fans |
48V BLDC |
|
Heating Function |
Yes |
|
|
|
|
Power Consumption |
||
Rated Power Input |
Watts |
500 W |
Rated Current |
Amps |
11.1 A |
Input Voltage Range |
DC |
42-59 V |
|
|
|
Dimensions |
||
Shipping Size |
21.7 x 24.4 x 17.3” |
|
Product Size |
17.7 x 21.3 x 13.8” |
|
Weight |
Net |
68 Lbs |
Gross |
73 Lbs |
Performance - 12,000 BTU/h unit |
||
Capacity |
Cooling |
12,000 BTU/h |
3,000 Watts |
||
Heating |
13,000 BTU/h |
|
3800 Watts |
||
Air Flow |
295 CFM |
|
EER |
W/W |
5.00 |
BTU/h/W |
15.79 |
|
Refrigerant |
R-134A |
|
Compressor |
Panasonic 48VDC |
|
Fans |
48V BLDC |
|
Heating Function |
Yes |
|
|
|
|
Power Consumption |
||
Rated Power Input |
Watts |
700 W |
Rated Current |
Amps |
15 A |
Input Voltage Range |
DC |
42-59 V |
|
|
|
Dimensions |
||
Shipping Size |
21.7 x 24.4 x 17.3” |
|
Product Size |
17.7 x 21.3 x 13.8” |
|
Weight |
Net |
68 Lbs |
Gross |
73 Lbs |
SPEC SHEET
Capacity |
Cooling |
12,000 BTU/h |
3,000 Watts |
||
Heating |
13,000 BTU/h |
|
3800 Watts |
||
Air Flow |
295 CFM |
|
EER |
W/W |
5.00 |
BTU/h/W |
15.79 |
|
Refrigerant |
R-134A |
|
Compressor |
Panasonic 48VDC |
|
Fans |
48V BLDC |
|
Heating Function |
Yes |
|
|
|
|
Power Consumption |
||
Rated Power Input |
Watts |
700 W |
Rated Current |
Amps |
15 A |
Input Voltage Range |
DC |
42-59 V |
|
|
|
Dimensions |
||
Shipping Size |
21.7 x 24.4 x 17.3” |
|
Product Size |
17.7 x 21.3 x 13.8” |
|
Weight |
Net |
68 Lbs |
Gross |
73 Lbs |
