154V Fully Electric 60kW (80HP) Skid Steer Enclosed Cabin w/AC 5400 LBF

154V Fully Electric 60kW (80HP) Skid Steer Enclosed Cabin w/AC 5400 LBF

Regular price $74,900.00 USD
Regular price Sale price $74,900.00 USD
Sale Sold out

Ready at all times with no fumes and no maintenance, the Full Battery FBX-1 Fully Electric Skid Steer features a rated load of 2,000 Lbs with a 4,000 Lbs tipping load and a top travel speed of 7.5 MPH. Four independent 12 kW motors drive each wheel, while a fourth 12 kW motor independently powers the hydraulic pump at 17 gpm. Standard American skid steer attachment plate for your favorite attachments. 5400 LBF breakout Force.

Equipped with a 154 Volt 54 kWh Lithium Iron Phosphate maintenance-free battery, this skid steer can serve your backyard, your business, farm, or large backyard daily. Order alone or with a solar charging system specifically made for your skidsteer to keep it topped off year-round. No oil changes, no fuel - just maintain your hydraulic system, and this little guy will amaze you with its prowess for years to come.

With this toy, you can dig your own pool, make your own mountain, use as a fork lift to move stuff on pallets, drill post holes, mix concrete, grade, and more.

We offer a full line of attachments for this unit. Price includes delivery within the lower 48 US States. Delivery within 6-10 weeks of deposit payment. Deposit: 20%, 80% due on the day of delivery. You pick the color.

Global delivery. Upon receiving your deposit, the factory will begin producting the unit in the color of your choice. We will send you pictures as the unit is built and ready for shipment.

Final payment is due on day of delivery for USA customers, and prior to shipping from the factory (located in China) for global customers. Consequently, domestic customers can delay payment of the remaining balance until the unit is delivered.

To receive a formal PDF quote or proforma invoice for your order, please add to cart and go to checkout. Upon checkout, you can submit the order using the Purchase Order option to bypass payment. This will allow us to furnish you with the quote with your billing / shipping details on it in the most efficient manner.

SPEC SHEET

Model

FBX-154

Main Parameters

Operating weight

3300Kg

Load rating

900Kg

Travel speed

0-13km/h

Wheel Motors

Motor type

Permanent magnet synchronous motor (PMSM)

Rated power of motor

12kw

Motor  Duty  Rating

S9 Duty with non-periodic load and speed  variations

Hydraulic Pump Motor

Rated power of motor

12Kw

Motor  Duty  Rating

S9 Duty with non-periodic load and speed  variations

Battery

Battery Type

Lithium iron phosphate

Battery Voltage

153.6V

Battery rated

capacity

53.6kwh(standard)

Battery weight

260kg

Charging time

AC220V Charge 1.5h

Operating time with

full load

5.5h

Operating time

with rated load

4-5h

Intermittent

operation time

8+ hours

Electrical

system

Voltage of

electrical system

12V

Tipping

load with

bucket ISO8313

Tripping load when  straight line driving

1250Kg

Tripping load when  full turn

900Kg

Hydraulic

drive system

Displacement

12 cc

Working pressure

170bar

Hydraulic oil

capacity

80L

Tires

Specifications

12-16-15

Total width

1720mm

Rated operating load

900kg

Bucket capacity rated

0.5m3

Bucket rise time

4.5s

Tipping load

1852kg

Bucket  breakout force, bucket cylinder


>24KN

Breakout force ,lift cylinder

>23KN

Speed

0-13km/h

Both length

3450

Both Width

1850

Bucket Width

1900

Both height

1950

Wheelbase

1050

Tread

1430

Max.dumping height

≥2550

Dumping reach

≥603

Min.group clearance

229
